Poynting Antennas LTE/GSM Marine A-OMNI-0291-V2 N-Type (F) Marine 7dbi omnidirectional OMNI-291 N-Type-F "LTE compatible"

Poynting LTE/GSM Marine Antenna OMNI-291-V2 N-TYPE (F) - White

GSM Antenna Marine 7dbi Omnidirectional OMNI-291 N-Type-F "LTE Compatible"

overview

The OMNI-291 is a high-performance marine antenna. This antenna uses a standard 1-inch (14 TPI) marine mount for simplified installation on most marine equipment. The ultra-wide frequency band covers all current LTE operating frequencies and provides excellent balanced gain across all frequencies, including the LTE and CDMA 450 MHz bands commonly required for marine applications. Higher frequencies are unaffected, and the antenna design allows Poynting superior pattern control across the entire frequency range, making the OMNI-291 a true high-performance omnidirectional antenna. The OMNI-291 guarantees signal reception almost anywhere along the coast, allowing it to be deployed in all parts of the world. Poynting Antennas achieves this through a new antenna configuration that utilizes multiple dipoles and a unique (patented) feed network. The antenna is future-proof as it covers the 450 MHz LTE frequency, which is becoming increasingly popular in different regions and countries!

Characteristics

• Omnidirectional antenna with medium gain
• Specially designed antenna for marine and coastal applications
• Light
• UV and salt water resistant
• Robust and weather-resistant
• Use in the 2.4 - 2.5 GHz Wi-Fi band

scope

• Marine / Yachts / Boats / Ferries
• Improved LTE reception
• IoT and M2M
• Poor reception of data signals
• Improving the reliability and stability of data transmission
• Wi-Fi applications

Technical data

• Frequency band: 450-470 MHz, 698-960 MHz, 1710-2700 MHz
• Gain max: 7 dBi
• Connection type: M-Type female
• Operating temperature: -40° - +80° C
• Waterproof according to IP68
• Wind survival time: <186 km/h
• Environmental conditions: Outdoor/Indoor
• Protection class/standard for water ingress: IP 68
• Salt spray: MIL-STD 810F/ASTM B117
• Relative humidity during operation: Up to 98%
• Storage humidity: 5% to 95% - non-condensing
• Storage temperature: -40°C to +80°C
• Housing flammability rating: UL 94-HB
• Impact resistance: IK 08
• Product dimensions (L x W): 560 x 75mm
• Packed dimensions: 580 x 95 x 90mm
• Weight: 800 g
• Packaged weight: 950 g
• Radome material: ABS (halogen-free)
• Housing color: white
