Teltonika · Tracker GPS · FMB230 · Vehicle · 2G Bluetooth Advanced GPS Tracker

Teltonika FMB230 2G Bluetooth GPS Tracker

available from February 2022!

overview

FMB230 is a WATER AND dust resistant tracker with internal GNSS, GSM antennas, configurable digital/analog inputs/negative input/pulse inputs, three DOUT outputs, Bluetooth connectivity and backup battery.

FMB230 is developed on the existing Teltonika platform and therefore retains all the functionalities of FMB130 with additional IP67 resistance to dust and water.

This tracker is dustproof and protected from the effects of temporary immersion in water. It can be mounted inside and outside a vehicle without fear of high pressure water, mud or dusty environment affecting its operation or performance quality. This is especially relevant for the industries that face harsh conditions such as agriculture, construction and mining and more.

Besides FMB130, FMB230 has 3xDOUT, which allows you to use 3 different DOUT scenarios at the same time, such as immobilizer, buzzer, alarm lights, door lock and others.

This tracker also has a negative input option that allows you to save your valuable integration time while connecting accessories such as vehicle door sensor, alarm button, seat belt detection and similar sensors or accessories. At the same time, Impulse Input can be used for fuel flow meter data reading. Pulse based fuel consumption control is much more accurate than various types of fuel level sensors and allows to be precise when required. It is the perfect solution for high fuel consumption machines such as cranes, construction vehicles, mining equipment and agricultural equipment.

Characteristics

• ip67 - Classifies the degree of protection against solid objects and water
• Configurable DIN/AIN/NIN for flexible remote monitoring and control.
• CAN data reading from vehicles and special transport (with CAN adapter)
• Bluetooth for external devices and low energy sensors
• Pulse inputs for data reading from fuel flow meters
• Battery - Allows the device to operate without an external power source

scope of delivery

• 1 x Teltonika FMB230 GPS Tracker
• 1 x Manual

For technical data see data sheet!

fmb230-datasheet.pdf (teltonika-gps.com)
