BUS/radio alarm centre, 50 ML, including LAN transmission device
Capacity: 50 radio or bus component signalling lines, 50 system usersFunctions: 8 security areas, 32 programmable PG outputs, 20 independent timersConnections: 5 adjustable AES/NSL connections, 5 selectable AES/NSL protocols
BUS/radio alarm centre, 50 ML, including LAN transmission device
- EN 50131: Grade 2
- Maximum number of devices 50
- Response to invalid code entry Alarm after 10 incorrect code entries
- Day/night mode
- BUS voltage (red - black) 12.0 to 13.8 V
- Maximum continuous current consumption from the control panel 1000 mA
- LAN communicator Ethernet interface, 10/100BASE-T
- Type A power supply unit (in accordance with EN 50131-6)
- Available connections for upgrading the control centre:
- 1 terminal block for connection to the bus
- 1 connection for a built-in radio module (JA-111R)
- 1 connection for a GSM/GPRS transmission device (JA-192Y)
Power supply: ~ 110 - 230 V/50 - 60 Hz, max. 0.28 A with fuse F1.6 A/250 V, safety class II
Backup battery 12 V; 7 Ah (lead gel)
Operating temperature: -10 °C to +40 °C
Dimensions: 357 x 297 x 105 mm
Optional: rechargeable battery 12V/7Ah (DXX-BS127)
Radio module AJA-JA111R,
GSM module 2G (AJA-JA192Y)
GSM module 4G (AJA-JA194Y)
Details about BUS/radio alarm centre, 50 ML, including LAN transmission device
| TYPE OF EQUIPMENT | Alarmzentrale |
|---|---|
| Connection | BUS Funk |
| EN 50131 (degrees) | 2 |
| Serie | JA-100 |
Manufacurer:
AJA-JA-103K-7AH
Weight:
0.000000
Storage:
