LoRa MCF88 LoRaWAN 4-20mA/0-10V to LoRaWAN® interface
LoRa MCF88 LoRaWAN 4-20mA/0-10V to LoRaWAN® interface
LoRa MCF88 LoRaWAN 4-20mA/0-10V to LoRaWAN® interface
This interface has two 4-20mA and two 0-10V input channels. All these inputs are opto isolated and are useful to connect any kind of analog sensor and to forward measurements to the LoRaWAN® platform.
Technical data:
- CPU Cortex M4 - RTC - EEProm 32KB - Flash 1MB - Encryption AES 128 bit - LiPo rechargeable battery - Class C LoRaWAN® stack EU868, AS923 - 1000Vdc isolated analog inputs - 2 analog current inputs 4-20mA 12bits with disconnect alarm - 2 analog voltage inputs 0-10V 12bits - USB On The Go - IoT node setup ad firmware upgrade via USB interface - Power supply 10-36Vdc - Storage temperature range -20 + 80 °C - Working temperature range -10 + 70 °C
Details about LoRa MCF88 LoRaWAN 4-20mA/0-10V to LoRaWAN® interface
Manufacurer:
Weight:
