Telegärtner cable Disconnect CP-Link, white, 0.2m, RJ45 male/female, DDCP-Link,

* Order-related order * Description of series/product category The DDCP-Link offers users and network managers an easy way to protect expensive mobile IT equipment with a LAN connection from damage. If the mobile IT equipment is moved in a larger radius than the connected RJ45 connection cable allows, the DDCP-Link releases the connection above a certain tensile force and protects the expensive circuit boards of the IT equipment from damage such as torn out contacts or loss of the RJ45 socket for the network connection. Expensive repairs are therefore a thing of the past. As the release force is below the standard specifications for RJ45 plugs and sockets in accordance with IEC 60603-7, it is ensured that the connection between the RJ45 connection cable and the DDCP link is released first. Nevertheless, the DDCP offers sufficient insertion and withdrawal forces to prevent unintentional release of the connection in the event of low tensile forces. The DDCP can be easily integrated into existing structures, e.g. by inserting it between the telecommunications connection box, connection cable and in front of the active device. Performance features

High Power over Ethernet plus (PoE+) in accordance with IEEE 802.3at Cable: S/FTP 4x2xAWG27/7 Cat.7 LSZH Outer cable diameter: 5.8 mm (+/- 0.2 mm) Service life = 750 mating cycles Wiring diagram 1:1 Assignment T568B plug with latching lever protection Plug and socket in accordance with IEC 60603-7-51 Temperature range: -40° C to 70° C Material shielding housing socket: nickel-plated die-cast zinc Material housing cover: ABS white Material contact surface: Ni1.2Au0.8
