AJAX | 8 channel NVR IP recorder | 4K | Alarm verification | Motion detection | H.265 | ONVIF | White
- Compatible with all HUBs
- 8 channels / 4K resolution / Up to 8 megapixels
- Connection via ONVIF / RTSP
- Recording with max. 100 MBit/s
- H.264 / H.265
- Motion detection
- Alarm verification
- Recording in case of alarm
- Tamper alarm
- In-app video management system
- 1 SATA port up to 16 TB
- Dimensions 251 × 251 × 51 mm
AJAX | 8 channel NVR IP recorder | 4K | Alarm verification | Motion detection | H.265 | ONVIF | White
The AJAX 8 channel NVR IP recorder is a video recorder for connecting IP cameras, including those from third parties with ONVIF and RTSP protocols. The recorder allows the installation of a hard drive with up to 16 TB storage capacity. Operation without a hard drive is also possible.
Product features:
- Add and configure IP cameras (camera resolution, brightness, contrast, etc.)
- View and zoom videos from added cameras in real time
- Watch videos in the chronology of recordings and navigate in the calendar (if a hard drive is installed)
- Motion detection in the recording area: NVR or camera
- Configure NVR motion detection (detection range, sensitivity)
- Multiscreen display
- Create video scenarios that send a short video from the selected camera to the Ajax app when a detector is triggered
Technical data:
| compatibility | Hub |
| Video stream |
|
| channels | 8 channels |
| IP cameras | ONVIF, RTSP |
| Storage | Hard drive with a capacity of up to 16 TB (SATA connection, 3.5 inches) |
Decoding formats | H.265, H.264 |
| Bandwidth | up to 100 Mbit/s |
| Communication channels |
|
| Ethernet | up to 100 Mbit/s |
| Bluetooth | BLE frequency band: 2.400 GHz to 2.4835 GHz For setting up an Ethernet connection. |
Radio signal power | 2.5 mW (100 mW limit) |
Key Features |
|
Motion detection | The NVR is equipped with its own software for detecting movements in the image. The image analysis can be carried out using either NVR or camera algorithms. |
In-app video management system |
|
Visual verification of Ajax alarms | The NVR can be used to set up a scenario in which certain cameras start recording when triggered by an Ajax detector. The results are displayed directly in the (surveillance) apps on the PC or mobile device. |
data protection | Assigning access rights to users in mobile apps and to monitoring personnel in PRO Desktop. |
Power supply |
|
Main power supply | 110 to 240 V~, 50/60 Hz, 0.6 A |
Emergency power supply | CR2032 battery, 3V |
Protection against sabotage | Tamper alarm |
Housing |
|
Dimensions | 251 × 251 × 51mm |
Weight | 700g (without hard drive) |
| Operating temperature range | from 0 °C to +40 °Cfrom 0 °C to +40 °Cfrom 0 °C to +40 °C |
| Operating temperature range Operating humidity | up to 75% |
| Protection class | IP20 |
Scope of delivery | NVR |
Scope of delivery:
- 1x AJAX | 8 channel NVR IP recorder | 4K | Alarm verification | Motion detection | H.265 | ONVIF | White
