Shelly · Flush-mounted · "1 Gen3" · Pack of 4 · Relay · max 16A · 1 channel · WLAN · BT
Shelly · Flush-mounted · "1 Gen3" · Pack of 4 · Relay · max 16A · 1 channel · WLAN · BT
WLAN-controlled smart switch with potential-free contacts, 1 channel 16 A
The Shelly 1 Gen3 is a smart switch with potential-free contacts. You can remotely control a variety of household and office devices from anywhere. Modernize your standard switch boxes, sockets and light switches or any other device with limited space.
- Potential-free contacts - option for contactor control
- Improved performance - ESP Shelly-C38F with increased 8 MB memory
- Longer durability of the clamps
- High security
- Wi-Fi range extender and Bluetooth gateway
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
- No HUB required! Easy control via Shelly Smart Control app, various home automation protocols, platforms and voice assistants.
WHY SHELLY 1 GEN3?
Versatile automation for every project
Our bestseller - now even more powerful, equipped with our Shelly chip. The Shelly 1 Gen3 is perfect for automating lighting, controlling garage doors and upgrading old appliances: the ideal choice for a more efficient, connected home or office. Thanks to its versatility, it is suitable for a wide range of automation projects.
functions
Wi-Fi-powered
Connect the Shelly 1 Gen3 to your WiFi network. No HUB required!
Bluetooth
Quick integration via Bluetooth or use as a Bluetooth gateway.
Potential-free contacts
Use it to control a variety of devices and appliances.
support for low and extra-low voltage
Use a wide range of output voltages. Supports low voltages.
Smart schedules
Set custom schedules based on your daily schedule or follow sunrise and sunset and control your lighting accordingly.
Smart Scenes
Combine the Shelly 1 Gen3 with other Shelly devices and set custom scenes.
Features of the Gen3 series
On the way to Matter
Every Gen3 device is designed to be upgradeable to Matter. Double the storage compared to the Plus series ensures a smooth upgrade process and paves the way for new smart features and integrations.
*Depending on the level of feature support provided by Matter.
More memory, more performance
The Gen3 series ensures the quality and reliability of our devices by using our powerful Shelly chip. With an impressive 8MB of memory, the performance and efficiency of the device is greatly improved. This significant memory increase not only guarantees smoother and faster operation, but also equips the Gen3 series to introduce new features.
Unified control with virtual components
The Gen3 series introduces "virtual components" that transform the way you manage and control third-party devices. Within the Shelly Smart Control app, you can now create virtual devices to integrate non-Shelly products into a unified control system. This feature allows for efficient control of all your smart devices, regardless of brand, from a single user interface.
Technical data
| PHYSICALLY | |
|---|---|
| Size (HxWxD): | 37x42x16 mm / 1.46x1.65x0.63 inches |
| Weight: | 26 g |
| Screw terminals max torque: | 0.4 Nm / 3.5 lbin |
| Cross-section of the conductor: | 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded and wire end ferrules) |
| Stripping length of the conductor: | 6 to 7 mm / 0.24 to 0.28 inches |
| Assembly: | flush-mounted box |
| Housing material: | plastic |
| Color of the case: | Blue |
| ENVIRONMENT | |
| Working temperature: | -20°C to 40°C |
| Humidity: | 30% to 70% relative humidity |
| Max. altitude above sea level: | 2000 m |
| Electric | |
| Power supply: | 110-240 V~24-48 V?12 V? |
| Device's own consumption: | < 1.2 W |
| nominal values of the output circuits | |
| Max. switching voltage: | 240 V~30 V? |
| Max. switching current: | 16 A (240 V~)10 A (30 V?) |
| sensors, measuring devices | |
| Internal temperature sensor: | Yes |
| radio | |
| Wi-Fi | |
| Protocol: | 802.11 b/g/n |
| Frequency band: | 2401-2483 ?Hz |
| Max. RF power: | < 20 dBm |
| Reach: | Up to 50 m outdoors, up to 30 m indoors (depending on local conditions) |
| BLUETOOTH | |
| Protocol: | 4.2 |
| Frequency band: | 2400 - 2483.5 MHz |
| Max. RF power: | <4 dBm |
| Reach: | Up to 30 m outdoors, up to 10 m indoors (depending on local conditions) |
| MICROCONTROLLER UNIT | |
| CPU: | ESP-Shelly-C38F |
| Flash: | 8 MB |
| FIRMWARE FEATURES | |
| Schedules: | 20 |
| WebHooks (URL actions): | 20 with five URLs per hook |
| Wi-Fi range extender: | Yes |
| BLE gateway | Yes |
| Scripting: | Yes |
| MQTT: | Yes |
| Encryption: | Yes |
