Shelly · Flush-mounted · "2PM Gen3" · 4-pack · Relay · max. 16A · 2-channel · WLAN · BT
Shelly · Flush-mounted · "2PM Gen3" · 4-pack · Relay · max. 16A · 2-channel · WLAN · BT
Wi-Fi controlled smart switch with two channels, 16 A total current (18 A peak)
The Shelly 2PM Gen3 is a smart switch with dual-channel control, power metering, and cover control. You can remotely control and monitor two different circuits or roller shutters, blinds, and other bidirectional motors. It's perfect for retrofitting standard electrical outlets, sockets, and light switches—even in tight spaces.
- Two channels on the same phase
- Power measurement on each channel
- Roller Shutter Control Automate and adjust the position of roller shutters, blinds, gates, curtains, awnings, sliding doors and other bidirectional motors
- Slat angle control Use the switch for your blinds and control the tilt position (angle) of the slats to adjust how much light shines into a room.
- New processor ESP-Shelly-C38F chip with increased memory capacity of 8 MB
- Improved terminal durability
- Virtual components
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
- No hub required! Easy control via the Shelly Smart Control app, various home automation protocols, platforms, and voice assistants
- Supports KNXnet / IP communication
Functions
Wi-Fi powered
Connect the Shelly 2PM Gen3 to your Wi-Fi network. No hub required!
Bluetooth
Quick integration via Bluetooth or use as a Bluetooth gateway.
Performance measurement
Two integrated precise energy meters allow you to monitor the consumption of each channel.
Slat angle control
Use it with your blinds and control the tilt position of the slats to adjust how much light enters a room.
Smart schedules
Set custom schedules based on your daily routine or control your lights according to sunrise or sunset.
Smart scene
Combine the Shelly 2PM Gen3 with other
Endless applications
Perfect start to the day
Automated curtains in the bedroom
Set the Shelly 2PM Gen3 to open your bedroom curtains at a specific time each morning using schedules. As you wake up, the curtains will gradually open, gently waking you and giving you the perfect start to your day.
Separate consumption recording
Control two lights with one device
The Shelly 2PM Gen3 allows you to control and monitor two different lights on the same phase with a single device. Each light's power consumption is measured separately for more efficient lighting. Use the manual switch, the app, your preferred smart home system, or your voice!
Reduce electricity costs
Energy management
Take control of your energy consumption with the power metering feature for each channel. Monitor and analyze the consumption of connected devices in real time and use this data to make informed decisions to reduce your energy costs.
Use daylight
Smart blinds
For an energy-efficient home, connect the Shelly 2PM Gen3 to your blinds. Automatically adjust them based on the time of day or weather conditions. For example, close them on hot days to keep your rooms cool. Raise the blinds in the morning, letting in natural light and reducing the need for artificial lighting.
Technical data
| Characteristics | ||
|---|---|---|
| Size (H x W x D): | 37 x 42 x 16mm / 1.46 x 1.65 x 0.63 inch | |
| Weight: | 27 g | |
| Screw terminals max. torque: | 0.4Nm / 3.5 lbin | |
| Cross-section of the conductor: | 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded and ferruled) | |
| Stripping length of the conductor: | 6 to 7 mm / 0.24 to 0.28 inches | |
| Assembly: | Flush-mounted box | |
| Housing material: | plastic | |
| Case color: | Black Environment | |
| Ambient temperature: | -20 °C to 40 °C | |
| Humidity: | 30% to 70% relative humidity | |
| Max. altitude above sea level: | 2000 m | |
| Electric | ||
| Power supply: | ||
| 110-240 V~ | ||
| 24 V? ±10% | ||
| Own consumption: | < 1.4 W | |
| Nominal values of the output circuits | ||
| Max. switching voltage: | ||
| - 240 V~ | ||
| - 30 V? | ||
| Max. switching current: | ||
| - 16 A (240 V~) | ||
| - 10 A (30 V?) | ||
| Sensors, measuring devices | ||
| Internal temperature sensor: | Yes | |
| Voltmeter (AC): | Yes | |
| Ammeter (AC): | Yes | |
| Security features | ||
| Overheating protection: | Yes (AC) | |
| Surge protection: | Yes (AC) | |
| Overcurrent protection: | Yes (AC) | |
| Overload protection: | Yes | |
| Obstacle detection: | Yes (blind mode) | |
| Safety switch: | Yes (blind mode) | |
| radio | ||
| Wi-Fi | ||
| Protocol: | 802.11 b/g/n | |
| Frequency band: | 2400 - 2495 Hz | |
| Max. RF power: | < 20 dBm | |
| Reach: | Up to 50 m outdoors, up to 30 m indoors (depending on local conditions) | |
| Bluetooth | ||
| Protocol: | 4.2 | |
| Frequency band: | 2400 - 2483.5 MHz | |
| Max. RF power: | < 4 dBm | |
| Reach: | Up to 30 m outdoors, up to 10 min indoors (depending on local conditions) | |
| Microcontroller unit | ||
| CPU: | ESP-Shelly-C38F | |
| Flash: | 8 MB | |
| Firmware features | ||
| Schedules: | 20 | |
| WebHooks (URL actions): | 20 with five URLs per hook | |
| WiFi repeater: | Yes | |
| BLE gateway: | Yes | |
| Scripting: | Yes | |
| MQTT: | Yes | |
| Encryption: | Yes | |
