Smart dimming control unit with power measurement
The Shelly Dimmer 0/1-10V PM Gen3 is suitable for controlling 0/1-10V dimmers and enables precise dimming with power measurement. It is retrofittable and can be used with any conventional switch you have at home.
- Supports 0-10V and 1-10V drivers (lamps, motors, valves, etc.)
- Wi-Fi and Bluetooth controlled
- Shelly Plus Add-On Compatible: Supports connection with the sensor interface to measure various data (humidity, temperature, etc.)
- Dimming mode with one or two buttons (use with conventional switches)
- Customizable thresholds and offsets for temperature, humidity and light when the dimmer is used with the Shelly Plus add-on
- Power measurement: Precise monitoring of energy consumption. Information on voltage (V), current (A) and consumption (W) is displayed.
- Protection: overcurrent/voltage/power protection
- "Night mode": Automatically sets the brightness of the lighting to a low level at night.
- Wi-Fi range extender & BLE gateway
- Equipped with a new processor and larger flash memory - ESP Shelly
- No hub required! Easy control via the Shelly Smart Control app, most platforms and protocols, and voice assistants. Use it with Alexa, Home Assistant, or your favorite automation platform.
WHY SHELLY SHELLY DIMMER 0/1-10V PM GEN3?
Use it with your existing wall switches!
Use the switches you already know and integrate the dimming function seamlessly into your current setup.
functions
Wi-Fi-powered
Connect the Shelly Dimmer 0/1-10V PM Gen3 to your WiFi network.
No HUB required!
Bluetooth
Quick integration via Bluetooth or use as a Bluetooth gateway.
performance measurement
Provides accurate monitoring of power consumption and free data storage.
Flexible input control
Use it with your existing switches, whether with one or two buttons.
Smart schedules
Set individual schedules based on your daily routine or follow the sunrise and sunset and control your lighting accordingly.
Smart Scenes
Combine the Shelly Dimmer 0/1-10V PM Gen3 with other Shelly devices and set custom scenes.
Features of the Gen3 series
On the way to Matter
Every Gen3 device is designed to be upgradeable to Matter. Double the storage compared to the Plus series ensures a smooth upgrade process and paves the way for new smart features and integrations.
*Depending on the level of feature support provided by Matter.
More memory, more performance
The Gen3 series ensures the quality and reliability of our devices by using our powerful Shelly chip. With an impressive 8MB of memory, the performance and efficiency of the device is greatly improved. This significant memory increase not only guarantees smoother and faster operation, but also equips the Gen3 series to introduce new features.
Unified control with virtual components
The Gen3 series introduces "virtual components" that transform the way you manage and control third-party devices. Within the Shelly Smart Control app, you can now create virtual devices to integrate non-Shelly products into a unified control system. This feature allows for efficient control of all your smart devices, regardless of brand, from a single user interface.
Technical data
| CHARACTERISTICS | |
|---|---|
| Size (H x W x D): | 38.5 x 43.5 x 17mm / 1.52 x 1.71 x 0.67 inches |
| Weight: | 28.5 g |
| Screw terminals max. torque: | 0.4 Nm / 3.5 lbin |
| Cross-section of the conductor: | 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded and wire end ferrules) |
| Stripping length of the conductor: | 5 to 6 mm / 0.20 to 0.24 inches |
| Assembly: | wall bracket / behind the wall / ceiling construction |
| Housing material: | plastic |
| FUNCTIONS | |
| Ambient temperature: | -20 °C to 40 °C |
| Humidity: | 30% to 70% relative humidity |
| Max. altitude above sea level: | 2000 m |
| CONNECTION | |
| Power supply: | 110-240 V~ 50/60 Hz |
| Device's own consumption: | < 1.5 W |
| External protection: | 16 A, tripping characteristic B or C, 6 kA breaking capacity, energy limitation class 3 |
| Max. switching voltage: | 240 V~ |
| Max. switching current: | 13 A |
| Max. control current: | 35 mA |
| Voltmeter (AC): | 110 - 240 V |
| Ammeter (AC): | 50 mA - 16 A |
| Accuracy of the measuring device: | ±10% |
| Power and energy meters: | Active and apparent power / active and apparent energy / power factor |
| Storage of measurement data: | No |
| Internal temperature sensor: | Yes |
| CONNECTIVITY | |
| WLAN protocol: | 802.11 b/g/n |
| Frequency band: | 2401-2495 MHz |
| Max. RF power: | < 20 dBm |
| Reach: | Up to 30 m outdoors and up to 50 m indoors (depending on local conditions) |
| Bluetooth protocol: | 4.2 |
| Frequency band: | 2400-2483.5 MHz |
| Max. RF power: | < 4 dBm |
| Reach: | Up to 30 m outdoors, up to 10 m indoors (depending on local conditions) |
| MCU | |
| CPU: | Shelly ESP32 C3 |
| clock frequency: | 40 MHz |
| Flash: | 8 MB |
| FIRMWARE CAPABILITIES | |
| Schedules: | 20 |
| WebHooks (URL actions): | 20 with five URLs per hook |
| Scripting: | Yes |
| MQTT: | Yes |
| Extended schedules: | Yes |
| Key-Value Database: | Yes |
