A 24-port, 2.5GbE, Layer 3 Etherlighting™ switch.
Etherlighting™ ports that light up to indicate port location, speed/link, and native VLAN/network*
(8) 2.5GbE RJ45 ports
(16) GbE RJ45 ports
(2) 10G SFP+ ports
DC emergency power supply ready
Managed with UniFi Network 8.0.24 and higher
Technical specifications
| Mechanically | |
|---|---|
| Dimensions | 442.4 x 325 x 43.7 mm (17.4 x 12.8 x 1.7") |
| Weight | Without mounting brackets: 4.2 kg (9.3 lb) With mounting brackets: 4.3 kg (9.5 lb) |
| Housing material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Network interface | (16) GbE RJ45 ports (8) 1/2.5GbE RJ45 ports (2) 10G SFP+ ports |
| Total non-blocking throughput | 56 Gbps |
| Switching capacity | 112 Gbps |
| Power method | Universal input, 100-240 V AC, 50/60 Hz USP RPS DC input |
| Power supply | AC/DC, internal, 50 W |
| Supported voltage range | 100–240 V AC |
| Max. energy consumption | 50W |
| LCM display | (1) 1.3-inch touchscreen |
| button | Factory settings reset |
| operating temperatur | -5 to 40 °C (23 to 104 °F) |
| Operating humidity | 10 to 90% non-condensing |
| Certifications | CE, FCC, IC |
| Etherlighting™ | |
| Ethernet | Localization the speed/connection of the native VLAN/network |
| SFP+ | Localization the speed/connection of the native VLAN/network |
| LED | |
| system | status |
| RPS | status |
| Application requirements | |
| UniFi Network | Version 8.0.24 and higher |
