Ubiquiti Switch smart managed Layer2 9 Port &bull 8x 2.5 GbE &bull 1x 10 GbE PoE at In &bull Desktop &bull Fanless &bull UniFi
Ubiquiti Switch smart managed Layer2 9 Port &bull 8x 2.5 GbE &bull 1x 10 GbE PoE at In &bull Desktop &bull Fanless &bull UniFi
Flexible 8-port 2.5GbE switch with a 10GbE RJ45/SFP+ combo uplink port that can be powered by a USB-C or PoE+ adapter.
Highlights:
- (8) 2.5 GbE ports
- (1) 10 GbE PoE+ input port for power / SFP+ port combination
- Optional power supply with included 5V, 3A USB-C adapter
Technical data:
| Mechanically | |
|---|---|
| Mass | 212.9 x 76 x 33.5 mm (8.4 x 3 x 1.3 inches) |
| Weight | 420 g (14.8 oz) |
| housing material | polycarbonate |
| assembly | Wall mounting possible (kit included) DIN rail mounting possible (sold separately) |
| Hardware | |
| management interface | Ethernet In-Band |
| network interface | (8) 2.5/1 GbE RJ45 ports (1) 10G SFP+ or 10/5/2.5/1 GbE combo port* If only one is active, GbE can be powered and SFP+ can be used for data. |
| Total non-blocking throughput | 30 Gbit/s |
| switching capacity | 60 Gbit/s |
| forwarding tariff | 44.64 Mpps |
| performance method | (1) Power adapter, 5 V DC, 3 A (1) PoE+ (PairA 1, 2+ 3, 6-)(PairB 4, 5+ 7, 8-) |
| power supply | External AC/DC adapter UniFi PoE switch |
| Supported voltage range | AC/DC input: 5 V DC PoE input: 42.557 V DC |
| Max. power consumption | 14W |
| button | factory reset |
| ambient temperature during operation | -20 to 45 °C (-4 to 113 °F) |
| humidity during operation | 10 to 90% non-condensing |
| certifications | CE, FCC, IC |
| switching functions | |
| Layer 2 functions | STP / RSTP with priorities and deactivation at port level storm control Multicast/Broadcast Rate Limiting Flow Control jumbo frames egress rate limit Proprietary loop protection port isolation port mirroring |
| LEDs | |
| system | Blue/white: power supply. Flashing white: Booting up. Flashing blue: Firmware update. Solid white: Factory settings device waiting to be adopted. Solid blue: Device has been adopted. |
| Ethernet | link/activity PoE input |
| SFP+ | link/activity |
| application requirements | |
| UniFi network | version 9.0.108 and higher |
