Ubiquiti Switch smart managed Layer2 9 Port &bull 8x 2.5 GbE PoE+ &bull 1x 10 GbE PoE bt In &bull Desktop &bull Fanless &bull
Ubiquiti Switch smart managed Layer2 9 Port &bull 8x 2.5 GbE PoE+ &bull 1x 10 GbE PoE bt In &bull Desktop &bull Fanless &bull
Flexible 8-port 2.5 GbE PoE++ switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered by PoE+++ or an AC power supply*.
Highlights:
- (8) 2.5 GbE PoE++ output ports
- (1) 10 GbE PoE+++ input port for power/SFP+ port combination
- 196W PoE availability with optional AC power adapter*
*Power adapter sold separately.
Technical data:
| Mechanically | |
|---|---|
| Mass | 212.9 x 99.4 x 33.5 mm (8.4 x 3.9 x 1.3 inches) |
| Weight | 567 g (20 oz) |
| housing material | polycarbonate |
| assembly | Wall mounting possible (kit included) DIN rail mounting possible (sold separately) |
| Hardware | |
| management interface | Ethernet In-Band |
| network interface | (8) 2.5/1 GbE RJ45 ports (1) 10G SFP+ or 10/5/2.5/1 GbE combo port* If only one is active, GbE can be powered and SFP+ can be used for data. |
| PoE interface | (8) 60W PoE++ (Pair A 1, 2+ 3, 6-) (Pair B 4, 5+ 7, 8-) |
| Total non-blocking throughput | 30 Gbit/s |
| switching capacity | 60 Gbit/s |
| forwarding tariff | 44.64 Mpps |
| performance method | (1) Power adapter, 54 V DC, 3.9 A (not included) (1) PoE+++ (PairA 1, 2+ 3, 6-)(PairB 4, 5+ 7, 8-) |
| power supply | External AC/DC adapter UniFi PoE switch |
| Supported voltage range | AC/DC input: 54 V DC (DC jack) PoE input: 5057 V DC |
| Max. power consumption | PoE input: 14 W (without PoE output) AC input: 17 W (without PoE output) |
| Total available PoE | PoE+++ input: 57 W PoE++ input: 37 W PoE+ input: 12 W 210 W AC adapter input: 196 W |
| Max. PoE power per port through PSE | PoE: 15.4 W PoE+: 30 W PoE++: 60 W |
| voltage range PoE mode | PoE: 4457 V PoE+/PoE++: 5057 V |
| button | factory reset |
| ambient temperature during operation | -20 to 45 °C (-4 to 113 °F) |
| humidity during operation | 10 to 90% non-condensing |
| certifications | CE, FCC, IC |
| switching functions | |
| Layer 2 functions | STP / RSTP with priorities and deactivation at port level storm control Multicast/Broadcast Rate Limiting Flow Control jumbo frames egress rate limit Proprietary loop protection port isolation port mirroring |
| LEDs | |
| system | Blue/white: power supply. Flashing white: Booting up. Flashing blue: Firmware update. Solid white: Factory settings device waiting to be adopted. Solid blue: Device has been adopted. |
| Ethernet | link/activity PoE input/output |
| SFP+ | link/activity |
| application requirements | |
| UniFi network | version 9.0.108 and higher |
