Ubiquiti UniFi Switch Flex / 1x POE++-In / 4x POE+-Out /up to15W per Port* / PoE / USW-Flex-3

Ubiquiti UniFi Switch Flex 3-Pack

5-port Layer 2 Gigabit switch with PoE support

The UniFi® Switch Flex is a managed Layer 2 Gigabit switch with auto-sensing 802.3af PoE support.

Model: USW-Flex

Features:

• (1) GbE, 802.3bt PoE++ RJ45 input
• (4) GbE, 802.3at PoE+ RJ45 ports
• Up to 46W total PoE supply*
• Weatherproof design
• Multiple mounting options

*When powered with a PoE++ switch or a 60W PoE injector (sold separately).

Managed with the UniFi Network application: Version 5.10.3 and later

PoE flexibility
The USW-Flex supports a maximum PoE output budget of 46W when powered by 60W 802.3bt PoE++. Four ports provide auto-sensing 802.3af PoE output to power multiple devices on the network.

Versatile assembly
The USW-Flex can be installed horizontally or vertically, making it ideal for desktop, magnetic wall and pole mounting.

Interior / exterior design
The USW-Flex is designed for indoor and outdoor use. With its weatherproof housing and versatile mounting options, the USW-Flex offers both flexibility and durability for environments with extreme temperature fluctuations.

Compatible products
The USW-Flex supports a variety of products including the UniFi G3 Flex Video Camera, UniFi G4 Pro Video Camera, and UniFi AC Mesh AP that use 802.3af PoE. To enable its maximum power budget of 46W, the USW-Flex can be powered by the USW-Industrial, US-XG-6POE, USW-Pro-24-PoE, or USW-Pro-48-PoE switches using 60W 802.3 bt PoE++.

Seamless integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a central interface. Each site is logically separated and has its own network monitoring, configuration, mapping, statistics, and administrator accounts.

Technical data:
