Funktel IP base station FB4 IP TP

PoE Cat 5/6 radio base station for high-performance communication networks

The FB4 IP PoE base station enables the implementation of high-performance DECT/IP communication networks for a wide range of circumstances and requirements. All wireless telephony functions of the central IP telephony system are supported via the base station. The DECT controller makes the configuration of the DECT network user-friendly and convenient.

Thanks to integrated contacts, the widest possible range of technical installations can be connected to the FB4. With its DECT messaging information, the FB4 can be used to forward specific events or conditions for each contact, such as temperature measurement, level indicator, door opening, motion sensors, etc.

Features:

- 12 channels
- 10 voice channels (8 if DSS/IMS is installed)
- 1 channel for synchronization, 1 carrier channel
- Supports Power over Ethernet (PoE) AND external power cable
- IEEE 802.3af PoE Class 1 (0.44 W to 3.84 W)
- LED status display
- Switch input (open or closed)
- Two connectors for external antennas
- PoE AND external power cable, max. cable length 100 m

Specifications:

- Dimensions: approx. 203 x 155 x 27 mm
- Temperature range: Operation: –10 ... +45 °C / Storage: –40 ... +85 °C
- Power supply: Power over Ethernet or separate power cable, 230 V
- Integrated contact connection for the transmission of certain events or states via switching contact, such as temperature measuring devices, level indicators, door contacts, motion detectors, etc.
- Explosion protection: Protection for Ex-Zone 1, Ex-Zone 2
- Network connection: Selectable - Ethernet TP
- Interface standard IEEE 802.3u – 100 Base TX Fast Ethernet (twisted copper cabling)
- IEEE 802.3 – 10BaseT Ethernet (twisted copper cabling)
- Network cable RJ45-8p, UTP Cat. 5 E (100 m max.)
- EIA/TIA-568 – 100 Ohm STP (100 m max.)
- PoE (Power over Ethernet) IEEE 802.3af, power class 1, powered via RJ45-8p pin (1, 2 and 3, 6)
- Phantom power via RX, TX, or powered via RJ45-8p pin (4, 5 and 7, 8), powered via unused pairs
- 0.44 ... 3.84 W, 36 ... 57 V
