Effekta Online-USV, 16000VA, 23min, MHD-Modular, 3(1)/1-Phasi

*Order-related, non-cancellable*,
UPS Modular 16 kVA(11.2KW), online double converter
23 min, 1/1 or 3/1-phase, black, RS232
modular design in 6-slot cabinet
LAN Powershut+M2505 cable
with the following specifications:
Online double converter with sine output, modular design in 6-slot cabinet
1 x 230 VAC or 3 x 400 VAC
Input frequency: 50/60 Hz ± 8%
Power factor: 0.98
Total output power: 16000 VA / 11200 W
Output voltage: 1 x 230 VAC ± 2%
Output power per module: 16000 VA / 11200 W
Number of modules: 4 (expandable up to max. 6 modules)
Output frequency: 50/60Hz ± 2%
Overload capacity: 110-130% for 30s, >130% for 2s
Charging current: max. 3.5 A per module
Autonomy time: 23 minutes at rated load, extendable
Batteries: maintenance-free lead-acid batteries 360V/28Ah
with ten years expected service life
Battery type: 30 x EFFEKTA BT12-28
Dimensions UPS: 965x442x700 (HxWxD in mm)
Dimensions battery cabinet: 965x442x700 (HxWxD in mm)
Weight UPS: 90 kg
Battery cabinet weight: 405 kg
Furnishing:
Electronic bypass
LC display with various indications of operating states
RS232 (1x) and RS485 (3x) interface
Expansion slots (SNMP, relay)
Lan-PowerShut Shutdown and management software for all current
Operating systems (including RS232 cable)
Features:
Modular construction
Parallel-redundant configurable
Subsequent performance extension
Hot-swappable modules
Subsequent battery extension
