Effekta Online-USV,15000VA, 25min, Triton 3/3,

*Order-related, non-cancellable*, UPS Triton 15 kVA, online continuous. 25 min.,, 3/3-phase, black, Modular design with 1 module each 15kVA/13.5kW RS232, RS485, relay contacts IGBT rectifier LAN-Powershut+M2505 cable with the following specifications: UPS classification: Online double converter (VFI-SS-111) according to IEC 62040-3 Rectifier: IGBT rectifier bridge Input power factor: 0.99 Mains harmonics: <3% THD (current) Input voltage: 3 x 380/400/415 VAC +15% / -45% Input frequency: 50 / 60 Hz, +15% / -20% Inverter: IGBT inverter Output power: 15 kVA / 13.5 kW Output voltage: 3 x 380/400/415 VAC, adjustable Output frequency: 50 Hz ± 1% Overload capacity: up to 125% for 10 min., 125% for 10 min., 150% for 1 min. Nominal output current at 400 V: 19 A Short circuit current: 92 A (200ms) Crest factor: 3:1 Static bypass: Electronic thyristor switch, uninterruptible Overload capacity: 150% continuous, 1000% for 20ms Batteries: 432V/28Ah, maintenance-free lead-fleece batteries with 10-year service life expectancy Battery type: 72 pieces EFFEKTA BTL12-45 Charging current: max. 6 A Autonomy time: 25 minutes at nominal load, and cos phi 0.8 General: Dimensions UPS: 1200 x 600 x 780 (HxWxD in mm) Weight UPS: 504 kg Working temperature: 0 - 40°C, battery max. 20° C Heat loss: 575 W Cooling air flow: 504 cbm/h Noise level: max. 55dB(A) Protection class: IP20 Color: RAL 9004 Radio interference suppression: according to DIN EN 62040-2, class C3 Performance features: easy to maintain thanks to modular design, thus very low MTTR value IGBT rectifier very large input voltage window electronic bypass, manual service bypass extensive communication interfaces (2 x RS232, 2 x RS485, EPO, 1 x slot for relay card or SNMP, parallel port)
