Effekta online UPS, 60000VA, 7min at cos phi 0.7, Triton 3/3,

*UPS Triton 60 kVA, online duration 07 min., approx. 10 min. at 50kVA, 3/3-phase, black, modular design with 2 modules each 30kVA/27kW RS232, RS485, relay contacts IGBT rectifier LAN-Powershut+M2505 cable with the following specifications: UPS classification: online continuous converter (VFI-SS-111) according to IEC 62040-3 Rectifier: IGBT rectifier bridge Input power factor: 0.99 Mains perturbations: &lt3 % THD (current) Input voltage: 3 x 380/400/415 VAC +15% / -45% Input frequency: 50 / 60 Hz, +15% / -20% Inverter: IGBT inverter Output power: 60 kVA / 54 kW Output voltage: 3 x 380/400/415 VAC, adjustable Output frequency: 50 Hz ± 1% Overload capacity: up to 125% for 10 min., 125% for 10 min., 150% for 1 min. Rated output current at 400 V: 78 A Short-circuit current: 198 A (200 ms) Crest factor: 3:1 Static bypass: Electronic thyristor switch, uninterruptible Overload capacity: 150% continuous, 1000% for 20 ms Batteries: 432V/45Ah, maintenance-free lead-fleece accumulators with 10-year service life expectancy Battery type: 36 pieces EFFEKTA BTL12-45 Charging current: max. 20 A Autonomy time: 07 minutes at nominal load and cos phi 0.8 approx. 10 min. at 50kVA General: Dimensions UPS: 1200 x 600 x 780 (HxWxD in mm) Dimensions battery cabinet: 1200 x 600 x 780 (HxWxD in mm) Weight UPS: 189 kg Weight battery cabinet incl. batteries 795 kg Operating temperature: 0 - 40°C, battery max. 20° C Heat loss: 2300 W Cooling air flow: 1286 cbm/h Noise level: max. 55dB(A) Protection class: IP20 Color: RAL 9004 Radio interference suppression: according to DIN EN 62040-2, class C3 Performance features: easy to maintain due to modular design, therefore very low MTTR value IGBT rectifier very large input voltage window electronic bypass, manual service bypass extensive communication interfaces (2 x RS232, 2 x RS485, EPO, 2 x slot for relay card or SNMP, parallel port)
